ROUND X2 SERIES AC EMERGENCY VERSION
SKU RND X2 AC-EM
Description:
The RED SKY Round X2 AC Emergency is a robust LED luminaire engineered for harsh and hazardous areas, featuring 90-minute emergency backup at 1,800 lumens. With up to 11,758 lumens in normal mode, it supports 60°, 110°, and 180° beam angles. Certified for Zone 2 and 21, IP66, and ATEX/IECEx compliant, it offers superior safety and reliable illumination. Built in the USA and assembled for fast delivery, it’s ideal for offshore platforms, chemical zones, and critical safety lighting needs.
Product Type & Application: Metal Processing, Agriculture, Area & Floodlight, High bay & Low bay, Oil and gas, Power Generation, Pulp, Paper and Wood, Water, Wastewater Treatment
Specs
Compliance
Download
Electrical Parameters
Power (W)
25W, 45W, 65W, 75W
VOLTAGE(V)
100-240V AC
Frequency
50/60Hz
Power Factor
≥0.90
THD
<20%
L70
147,000 hrs@50°C
Surge Protection
L/N-FG 2KV，L-N 1KV
Warranty
Fixture: 5 Years, Battery: 1 Year
Optical Parameters
Lumen Output (Normal)*
4,036Lm, 7,129Lm, 10,405Lm, 11,758Lm
Lumen Output (EM)*
1,800Lm
Lumen Efficacy*
150Lm/W
Available Beam Angle
60°/ 110° /180°
Correlated Color Temperature (CCT)
4000K/5700K
Color Rendering Index (CRI)
Ra>70
Mechanical Parameters
Hardware
Stainless steel 316
Lens Material
Tempered Glass
Mounting Options
Ceilingt, Pendant, Yoke, Stanchion
Product Weight
19.4lbs/8.8kg
Cable Entry
(3) 3/4″ NPT
Product Dimensions(L×W×H)
11.9×10.6×14.7in (302×269.4×372.7mm)
Environmental Parameters
Ambient Operating Temperature
-0°C~+50°C
