SERIOUSLY SAFE LIGHTS™

Modular Hot Series

SKU MDH

Description:

Introducing the Modular Hot Series by Red Sky Lighting, the ultimate solution for high temperature environments. Designed with up to four LED modules, our Modular Hot Series provides unparalleled light output, equivalent to 400-2000W HID/MH lighting (30,500 to 114,500 lumens), while simultaneously reducing maintenance and energy costs by approximately 70%.

Product Type & Application: High bay & Low bay, Metal Processing
Electrical Parameters

Power (W)

200W, 400W, 600W, 800W

VOLTAGE(V)

120-277V AC / 347-480V AC

Frequency

50/60Hz

Power Factor

>90%

THD

<20%

L70

110,000 Operation Hours@158°F

Dimming

0-10V

Surge Protection

6KV

Warranty

5 years

Optical Parameters

Lumen Output

MDH-200: 30,521Lm
MDH-400: 57,516Lm
MDH-600: 87,595Lm
MDH-800: 114,598Lm

Lumen Efficacy

150Lm/W

Beam Angle(s)

15°/30°/60°/90°/30*120°/T3 (Polycarbonate)/120°(Glass)

CCT

5000K

CRI

Ra>70

Mechanical Parameters

Finish

Thermoset Powdercoat

Hardware

Stainless steel 316

Lens Material

Tempered Glass or Polycarbonate

Mounting Options

Yoke

Product Weight

MDH-200: 21lbs/9.5kg
MDH-400: 38.8lbs/17.6kg
MDH-600: 62.2lbs/28.2kg
MDH-800: 80.6lbs/36.6kg

Connection

MDH-200: 5ft Power Cord
MDH-400/600/800: 3ft Power Cord

Product Dimensions(L×W×H)

MDH-200:
16.5×10.6×10.9in(420x270x277mm)
MDH-400:
19.5×16.5×10.9in(495x420x277mm)
MDH-600:
29.1×16.5×10.9in(740x420x277mm)
MDH-800:
38×16.5×10.9in(964x420x277mm)

Environmental Parameters

Maximum Ambient Temperature

Glass:158°F(70°C), PC: 149°F(65°C)

Installation

MIN 90°C SUPPLY CONDUCTORS
