Description:
When the power goes out, keep hazardous locations safe and illuminated. Bringing the same robustness, cost-efficiency, and safety, the Linear Tuff now boasts a 90 Minute emergency battery backup. Suitable for petrochemical facilities, drilling rigs, platforms, loading docks, mining, oil and gas refineries, tunnels, and other hazardous locations.
Specifications
Rating & Classifications
Downloads
Electrical
Power (W)
EM: 6W, 80W
Voltage(s)/Frequency
120-277V AC
Power Factor
>95%
THD
<10%
L70
140,000 Hours@113°F
Surge Protection
6KV
Optical
Lumen Output
EM: 812Lm, 10057Lm
Lumen Efficacy
Up to 123Lm/W
Beam Angle(s)
60°, 110°, Type II
CCT
3000K, 4000K, 5000K
CRI
Ra>70
Mechanical
Ambient Operating Temperature
-4°F to +113°F (-20°C to 45°C)
T-Code Rating
CID2 – T4A
Housing Construction
Marine Grade Cast Aluminum
Housing Finish
Thermoset Powercoat
Lens Material
Tempered Glass
Mounting Options
Pendant, Yoke Bracket, Chain, Pipe
Weight
29.8lbs/13.5kg
Dimensions (L×W×H)
43.3×5.8×7.3 (1100×148×185 mm)
Connections
(3) 3/4″ NPT
Warranty/Certifications
Warranty Terms
Battery: 5 years, Driver: 7 years, LEDs: 10 years
Class I Division 1, Groups C,D
Class I, Zone 1, Group IIA
Class I, Zone 1, Group IIB
CSA C22.2 No. 141-15
CSA C22.2 No. 137-M1981
CSA C22.2 No.30-M1986
UL 844 Hazardous Location
UL 924 Emergency Lighting Equipment
UL 1598A Marine Vessels
UL 1598 Wet Locations
UL 8750 LED Safety
DLC (Contact Us)
ABS (pending)
IP66
